RESI9 XE plug-in circuit breaker 10A 3kA
RESI9 XE plug-in circuit breaker 10A 3kA
Regular price
€7,98 EUR
Regular price
Sale price
€7,98 EUR
Unit price
/
per
Couldn't load pickup availability
Technical characteristics
| Description | This miniature plug-in modular circuit breaker (XE) Resi9, 10A rating, C curve promises simplicity and adaptation to all your needs. In new construction or renovation, you can add features to an existing panel, for example. The circuit breaker is installed in the residential electrical panel, to provide protection up to 10A. With a simple gesture, installation is quick: assembly and electrical connection are simultaneous on the XE distributor, which directly supplies the modular circuit breaker. This plug-in modular circuit breaker (XE) guarantees a more peaceful way of working. With a rounded profile, it frees up work space between each row for easier wiring. White product (RAL 9003) delivered in its unit packaging. Downstream terminal: direct automatic plug-in terminals for 2 rigid or flexible cables without end cap from 1.5 to 2.5mm². The performance of this R9EFC610 product meets international standards and approvals such as NF, EN/IEC 60898. This product is certified Green Premium, the ecolabel that is committed to sustainable and environmentally friendly performance. It has a PEP (Product Environmental Profile) sheet. For protection of different calibers, there are plug-in circuit breakers of caliber 2A, 6A, 10A, 16A, 20A, 25A, 32A. For troubleshooting or adding a plug-in circuit breaker to an existing paintable panel, it is possible to use a connection accessory (UniXE). Automatic upstream/downstream connections provide high reliability to the connections and guarantee perfect contact over time With complete confidence for you, but also for your customers, Schneider Electric equipment meets the highest quality standards in both its design and its manufacture This model has the following characteristics - Curve C: general applications, control and protection against circuit overcurrents, magnetic tripping device acting between 5 and 10 hours, - 10 A, - Width 2 steps of 9 mm, - 1P + N, 230 V AC, - Breaking capacity 3,000 A (according to NF EN 60898), - Limitation class 3 (according to NF EN 60898), - Power supply by plugging into an XE distributor - Departure: 2 to 20 A direct plug-in terminals for 2 rigid or flexible cables without end cap from 1.5 to 2.5 mm2 / 32 A cage terminals 16 MM2 Resi9 is a range of electrical boxes, communications boxes and modular equipment for electrical installations with limited power connections. |
| Number of poles | 1 Ph + N |
| Intensity (A) | 10 A |
| Interrupting Power (ICC) | 3 kA |
| Curve | C |
| Electrical protection index | IP20 |
| Manufacturer Ref. | R9EFC610 |
| Brand | SCHNEIDER ELECTRIC |
| Standards | NF |
